| Model |
SUN-8K-SG01HP3
-US-AM2 |
SUN-10K-SG01HP3
-US-AM2 |
SUN-12K-SG01HP3
-US-AM2 |
SUN-15K-SG01HP3
-US-AM2 |
| Battery Input Data |
|
| Battery Type |
Lithium-ion |
| Battery Voltage Range (V) |
160-500 |
| Max. Charging Current (A) |
50 |
| Max. Discharging Current (A) |
50 |
| Charging Strategy forLi-ion Battery |
Self-adaption to BMS |
| Number of Battery Input |
1 |
| PV String Input Data |
|
Max. PV Access Power (W)
|
16000 |
20000 |
24000 |
30000 |
| Max. PV Input Power (W) |
12000 |
15000 |
18000 |
22500 |
| Max. PV Input Voltage (V) |
550 |
| Start-upVoltage (V) |
180 |
| MPPT Voltage Range (V) |
150-500 |
| Rated PV Input Voltage (V) |
380 |
| Max. Operating PV Input Current (A) |
26+26 |
| Max. Input Short-Circuit Current (A) |
39+39 |
| No. of MPP Trackers/No. of Strings MPP Tracker |
2/2+2 |
| AC Input/Output Data |
|
| Rated AC Input/Output Active Power (W) |
8000 |
10000 |
12000 |
15000 |
| Max. AC Input/Output Apparent Power (VA) |
8000 |
10000 |
12000 |
15000 |
| Rated AC Input/Output Current (A) |
22.3 |
27.8 |
33.4 |
41.7 |
| Max. AC Input/Output Current (A) |
22.3 |
27.8 |
33.4 |
41.7 |
| Max. Continuous AC Passthrough (grid to load) (A) |
80 |
| Peak Power (off-grid) (W) |
1.5 times of rated power, 10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V) |
120/208 0.85Un-1.1Un |
| Rated Input/Output Grid Frequency/Range(Hz) |
60/55-65 |
| Grid Connection Form |
3L+N+PE |
| Total Current Harmonic Distortion THDi |
<3% (of nominal power) |
| DC Injection Current |
<0.5% In |
| Efficiency |
| Max. Efficiency |
97.6% |
| Euro Efficiency |
97.0% |
| MPPTEfficiency |
>99% |
| Equipment Protection |
| Integrated |
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
|
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
| Communication Interface |
RS485/RS232/CAN |
| Monitor Mode |
GPRS/WIFI/Bluetooth/4G/LAN(optional) |
| General Data |
| Operating Temperature Range (℃) |
-40 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude |
2000m |
| Noise (dB) |
≤55 |
| Ingress Protection(IP) Rating |
TYPE3R |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC), OVC III(AC) |
| Cabinet Size (WxHxD mm) |
408×678×247 (Excluding Connectors and Brackets) |
| Weight (kg) |
30 |
| Type of Cooling |
Intelligent Air Cooling |
| Warranty |
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
| Grid Regulation |
IEEE 1547.1,SRD V2.0 |
| Safety / EMC Standard |
FCC, UL 1741 |
