| Model |
SUN-4K-G06 |
SUN-5K-G06 |
SUN-6K-G06 |
SUN-7K-G06 |
SUN-8K-G06 |
SUN-10K-G05 |
SUN-12K-G06 |
| PV String Input Date |
|
| Max. PV Input Power(kW) |
5.2 |
6.5 |
7.8 |
9.1 |
10.4 |
13 |
15.6 |
| Max. PV Input Voltage(V) |
1100 |
| Start-up Voltage(V) |
140 |
| MPPT voltage range(V) |
120-1000 |
| Rated PV Input voltage(V) |
600 |
| Max. Operating PV Input Current (A) |
13+13 |
| Max. Input Short Circuit Current (A) |
19.5+19.5 |
| No. of MPP Trackers/No. of Strings per MPP Tracker |
2/1+1 |
| AC Input/Output Side |
|
| Rated AC Output Active Power(kW) |
4 |
5 |
6 |
7 |
8 |
10 |
12 |
| Max. AC Output Apparent Power(kVA) |
4.4 |
5.5 |
6.6 |
7.7 |
8.8 |
11 |
13.2 |
| Rated AC output current (A) |
6.1/5.8 |
7.6/7.3 |
9.1/8.7 |
10.7/10.2 |
12.2/11.6 |
15.2/14.5 |
18.2/17.4 |
| Max. AC Output Current(A) |
6.7/6.4 |
8.4/8 |
10/9.6 |
11.7/11.2 |
13.4/12.8 |
16.7/16 |
20/19.2 |
| Rated output voltage/range (V) |
220/380V, 230/400V 0.85Un-1.1Un |
| Grid Connection Form |
3L/N/PE |
| Rated Output Grid Frequency/range(Hz) |
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading to 0.8lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
|
| Max. Efficiency |
98.3% |
| Euro Efficiency |
97.8% |
| MPPT Efficiency |
＞99% |
| Equipment Protection |
|
| DC Polarity Reverse Connection Protection |
yes |
| AC Output Overcurrent Protection |
yes |
| AC Output Overvoltage Protection |
yes |
| AC Output Short Circuit Protection |
yes |
| Thermal Protection |
yes |
| DC Terminal Insulation Impedance Monitoring |
yes |
| DC Component Monitoring |
yes |
| Ground Fault Current Monitoring |
yes |
| Power Network Monitoring |
yes |
| Island Protection Monitoring |
yes |
| Earth Fault Detection |
yes |
| DC Input Switch |
yes |
| Overvoltage Load Drop Protection |
yes |
| Residual Current (RCD) Detection |
yes |
| Surge Protection Level |
TYPE II(DC),TYPE II(AC) |
| Interface |
|
| Communication Interface |
RS485/RS232 /WiFi/LAN |
| General Data |
|
| Operating Temperature Range (°C) |
-25 to +60℃, >45℃ Derating |
| Permissible Ambient Humidity |
0~100% |
| Permissible Altitude (m) |
4000m |
| Noise (dB) |
＜45 |
| Ingress Protection(IP) Rating |
IP 65 |
| Inverter Topology |
Non-Isolated |
| Over Voltage Category |
OVC II(DC),OVC III(AC) |
| Cabinet Size (WxHxD mm) |
283*463*178（Excluding connectors and brackets） |
| Weight [kg] |
11 |
| Warranty [year] |
5 years |
| Type Of Cooling |
Natural Cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE-Richtlinie R25, G99, VDE-AR-N 4105
|
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
